2017 Mercury 15 HP 15EH Outboard Motor

SKU: 47e5172c4c8a Category: Mercury Outboard Motors

Description

2017 Mercury 15 HP 15EH Outboard Motor

The large 21.4 cubic inch displacement powerhead of the Mercury 15hp develops plenty of low-end torque, making it an excellent source of power for medium to larger sized jon boats, skiffs, and inflatables.

Mercury’s multi-function tiller handle and vibration-absorbing wishbone mounts are just a few of the exclusive features found on Mercury 15hp models.

2017 Mercury 15 HP 15EH Outboard Motor

Large Displacement Powerhead (351cc)
Electric Start + 12V 138W 12A Alternator
Thru-Cowl Backup Manual Start
Digital CD Ignition with Spark Advance
Tuned Intake for Quick Acceleration
High Grade Marine Alloy Construction
Stainless Steel Water Pump Housing
Zinc Coated Water Passages
Rated for Saltwater Use
Sacrificial Zinc Anodes and Trim Tab
Tiller Integrated F-N-R Gear Shifting
Adjustable Steering Tension Control
Twist-Grip Throttle with Tension Control
Thermostat Controlled Water Cooling
Shallow Water Drive
Quiet Through-Propeller-Hub Exhaust
“Wishbone” Mount for Reduced Vibration
6.6 Gallon Fuel Tank and Fuel Line
Easy Maintenance Canister Oil Filter
Start-In-Gear Protection
Low Oil Pressure Warning Indicator
ESG Over-Rev Protection
Safety Lanyard Stop Switch
Owner’s Manual
Mercury Marine 3-Year Warranty

2017 Mercury 15 HP 15EH Outboard Motor

Model	15EH
Model Year	2017
SKU	15EH-17
Weight	121.0000
Manufacturer	Mercury
Country of Manufacture	Japan
Horsepower	15hp
Shaft Length	15″ (Short)
Steering	Tiller
Starting	Electric
Trim & Tilt	Manual
Fuel Delivery	Carburetor
Fuel Tank	External
Cylinder(s)	2
Displacement	351 cc (21.4 cubic inches)
Bore and Stroke	61 x 60 mm (2.40 x 2.36 inches)
Full Throttle RPM Range	5000-6000
Ignition System	Digital CD Ignition w/Electronic Spark Advance
Induction Scavenging	SOHC
Valves per Cylinder	2
Fuel Type	87 Octane (up to 10% ethanol content)
Fuel Tank / Fuel Line	6.6 Gal. Fuel Tank + Quick Connect Fuel Line
Oil Type	SAE 10W-30 (Mercury 4-Stroke Outboard Oil)
Oil Capacity	1 Quart (1000 ml)
Lubrication	Trochoid Pump
Alternator	12V 138W 12A (standard on electric start models)
Cooling System	Water-Cooled, Thermostatically Controlled
Saltwater Rated	YES
Gear Ratio	2.15:1
Gear Shift	Forward-Neutral-Reverse (shift in tiller handle)
Propeller	9.2″ Diameter X 9.8″ Pitch 3-Blade Aluminum
Internal Battery	No
